Lynxspring LYNX-WD-013-01 : Dedicated high definition 10 inch touch screen display and mounting kit with kiosk mode for local feedback and control of your Niagara application or other web enabled BMS. High-quality framed wall mounting (tamper resistant) with concealed wiring, suitable for highfootfall areas. Compatible with any BMS controller or station that generates HTML5 web content. Can be panel or wall mounted. WiFi or Ethernet installation options are available.
Lynxspring LYNX-WD-010-02 : Dedicated high definition 10 inch touch screen display and mounting kit with kiosk mode for local feedback and control of your Niagara application or other web enabled BMS. High-quality framed wall mounting (tamper resistant) with concealed wiring, suitable for highfootfall areas. Compatible with any BMS controller or station that generates HTML5 web content. Can be panel or wall mounted. WiFi or Ethernet installation options are available.
ABB eXplore-C7 :eXplore graphical interface is an Internet of Things (IoT) touch-screen solution that is scalable and secure, able to control, monitor and manage future-ready smart buildings. (Approval Required for Purchase)
ABB eXplore-C10 : eXplore 10" IP-based capacitive touchscreen color display. Comes with universal power adapter and panel/enclosure mounting kit. (Approval Required for Purchase)
Lynxspring 485SD9TB : RS-485 to RS-232 Convertor when using the on-board RS-485 port on the JENE or JACE controller to provide communications to the LCD Interface Device (Requires 9-MA09M11 to adapt to the RJ11 connection on the LCD).
Lynxspring 9-MA09F11 : RJ11 to 9pin Female Adaptor when using the on-board RS-232 port on the JENE or JACE controller to provide communications to the LCD Interface Device.
Lynxspring JENE-PCLCD-R : Remote LCD Interface Device for NiagaraAX JENE and JACE controllers. Provides a non software interface into the controllers points, schedules, alarms, system info, etc.
Lynxspring JENE-PCLCD-R-LOCAL-6 : LCD Interface kit for mounting the LCD remotely (Up to 6ft). Includes; 1 LCD Interface Device, 1 LCD Trim Ring for panel or wall mounting, 1 LCD communication card, 1 6 ft cable (TEL-6000-06K-RJ11).
Lynxspring JENE-PCLCD-R-Service : LCD Interface kit for with necessary parts to use a hand held or portable service tool Includes; 1 LCD Interface Device, 1 power supply, 1 RS232 adaptor, 1 LCD communication card and two cables. 4 AA Batteries not included.
Lynxspring JENE-PCLCD-R-Local : LCD Interface kit for mounting the LCD remotely (Up to 50ft). Includes; 1 LCD Interface Device, 1 LCD Trim Ring for panel or wall mounting, 1 LCD communication card, 1 50 ft cable (8101-64150).
Lynxspring JENE-PCLCD-R-Remote : LCD Interface kit for mounting the LCD remotely (50ft to 4000ft). Includes; 1 LCD Interface Device, 1 LCD Trim Ring for panel or wall mounting, power supply and 1 RS485 Convertor.
Lynxspring JENE-PCLCD-R-Unit : LCD Interface kit for mounting the LCD directly onto the JENE controller. Includes; 1 LCD Interface Device, 1 Shroud adaptor for the controller and 1 LCD communication card with cable.
Lynxspring JENE-PC-LCDCARD : LCD Optional Communication Card for JENE and JACE controllers. Provides power and communcation to the LCD Interface Device when battery or wal-wart power are not used. (Approval Required for Purchase)
